〣Quality inspection standard

The quality requirements of fine grade galvanized sheet include specification size, surface, galvanized amount, chemical composition, plate shape, machine function and packaging.

1. packing

It is divided into two kinds: galvanized sheet     cut into fixed length and galvanized sheet packing with coil. General iron sheet packaging, lined with moisture-proof paper, outside with iron waist tie, tie firmly, to prevent the internal galvanized sheet friction.

2. Specification and size

The product dimensions (such as the following and) are listed in the galvanized sheet to promote the scale thickness, length and width and allowable faults. In addition, the width and length of the board, the width of the volume can also be determined by user request.

3. surface

General situation: Because of the difference in the treatment method of galvanized plate in the plating process, the general situation is also different, such as ordinary zinc flowers, fine zinc flowers, flat zinc flowers, zinc flowers and phosphating disposal situation. Galvanized sheet and galvanized coil cut to a fixed length shall not have defects affecting the use, but the coil is allowed to have welding parts and other less deformed parts.

4. Galvanizing amount

Galvanizing measure value: Measuring galvanizing measure is a widely adopted method to determine the thickness of zinc layer in galvanized sheet. There are two kinds of galvanized quantity the same on both sides (equal thickness galvanized) and zinc quantity on both sides (difference galvanized). Galvanized units are g/m2.

5. Machine function

(1) Tensile test: Generally speaking, as long as the layout, tensile and deep tensile galvanized sheet with tensile function requirements.

(2) Bending experiment: it is an important item to weigh the process function of thin plate. But the world to all kinds of galvanized sheet requirements are not the same. Generally, after the galvanized sheet is bent 180o, the outer coating shall not have the zinc layer to leave, and the substrate shall not have cracking and fracture.

6. Chemical composition

The requirements for the chemical composition of galvanized substrate vary from country to country. If Japan has such a requirement, the United States does not. Generally do not do product inspection.

7. Plate shape

There are two goals to weigh plate shape black and white, namely flatness and sickle bend. The flatness of the plate and the maximum allowable value of the sickle bend scale must be defined.

〣parameter
