410 stainless steel composition and characteristics

Semi-martensitic stainless steel has high strength and toughness after quenching and tempering, and has good corrosion resistance and machining properties in weak corrosive media with a temperature of not more than 30 degrees. In the wet atmosphere, fresh water conditions also have rust resistance and corrosion resistance, and have high thermal stability below 700 degrees. Good machinability but poor machinability and weldability.

1. 410 stainless steel corresponding grade: 1, national standard GB-T standard: digital grade: S41010, new grade: 12Cr13, old grade: 1Cr13,2. American standard: ASTMA standard: S41000, SAE standard: 51410, UNS standard: 410, 3, Japanese standard JIS standard: sus410, 4, German DIN standard: 1.4006, 5, European standard EN standard: X12Cr13.

2. 410 stainless steel chemical composition: (1) Carbon C: ≤0.15, (2) Silicon Si: ≤1.00, (3) Manganese Mn: ≤1.00, ⑷ Phosphorus P: ≤0.040, (5) sulfur S: ≤0.030, chromium Cr: 11.50 ~ 13.50, ⑺ Nickel Ni: allowed plus ≥0.60, (8) molybdenum Mo: -, nitrogen N: -, (10) Copper Cu: --, 11 Other elements: --.

3. 410 stainless steel physical properties: ① density density (20℃)

/ kg/dm3:7.7, (2) / ℃ melting point: 1480 ~ 1530, (3) heat capacity (0 ~ 100 ℃)/kg/kg. (k) : 0.46, (4) thermal conductivity/w/(m.k)

100℃-:24.2,⑸ Thermal conductivity /w/(m.k)

500 ℃ - :

28.9,⑥ line expansion coefficient

/(10-6/k)

0~100℃:11,⑦ linear expansion coefficient /(10-6/k)

0 ~ 590 ℃ :

11.7,⑧ Resistivity (20℃)

/ (.mm2/m):0.57,⑨ longitudinal elastic modulus

(20℃) /GPa:200, ⑩ Magnetic: Yes.

4. 410 stainless steel mechanical properties: (1) delivery status: bar solid solution treatment, plate solid solution pickling, (2) tensile strength (RM/MPa) : 540, 440, (3) extension strength (Rp0.2/MPa) : 345, 205, ⑷ elongation A/% : 55, 20, cross-section shrinkage (Z/%) : 78.

5. 410 stainless steel heat treatment: ① hardness HBW≤ : annealing 200, quenching and tempering 159, hardness HRB≤ : 93, ② heating temperature: 800~900, ③ heating method: air cooling or slow cooling.

410 stainless steel applications: mainly used for parts with high toughness requirements and stainless impact loads, such as tools, blades, fasteners, hydraulic valves, thermal cracking sulfur corrosion resistant equipment, etc., can also be made at room temperature conditions resistant to weak corrosive media equipment parts. Oxidation resistant parts below 650 degrees.
